一、hystrix基本介绍
Hystrix(https://github.com/Netflix/Hystrix)是Netflix(https://www.netflix.com/global)的一个开源项目,主要作用是通过控制那些访问远程系统、服务和第三方库的节点,从而对延迟和故障提供更强大的容错能力。 其可以看做是Netflix团队对分布式系统运维的各种理念和实践的总结。
二、基本用法
①pom.xml加上以下依赖
1
2
3
4
5
|
<dependency> <groupId>com.netflix.hystrix</groupId> <artifactId>hystrix-core</artifactId> <version> 1.5 . 8 </version> </dependency> |
②基本使用
1
2
3
4
5
6
7
8
9
10
11
12
13
|
public class HelloWorldHystrixCommand extends HystrixCommand<String>{ private final String name; public HelloWorldHystrixCommand(String name) { super (HystrixCommandGroupKey.Factory.asKey( "ExampleGroup" )); this .name = name; } @Override protected String run() throws Exception { //Thread.sleep(100); return "hello" +name; } } |
1
2
3
4
|
public static void main(String[] args){ String result = new HelloWorldHystrixCommand( "test" ).execute(); System.out.println(result); } |
或者
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
|
public class HelloWorldHystrixObservableCommand extends HystrixObservableCommand<String>{ private final String name; protected HelloWorldHystrixObservableCommand(String name) { super (HystrixCommandGroupKey.Factory.asKey( "ExampleGroup" )); this .name = name; } @Override protected Observable<String> construct() { System.out.println( "in construct! thread:" + Thread.currentThread().getName()); return (Observable<String>) Observable.create( new Observable.OnSubscribe<String>() { // @Override public void call(Subscriber<? super String> observer) { try { System.out.println( "in call of construct! thread:" + Thread.currentThread().getName()); if (!observer.isUnsubscribed()) { // observer.onError(getExecutionException()); // 直接抛异常退出,不会往下执行 observer.onNext( "Hello1" + " thread:" + Thread.currentThread().getName()); observer.onNext( "Hello2" + " thread:" + Thread.currentThread().getName()); observer.onNext(name + " thread:" + Thread.currentThread().getName()); System.out.println( "complete before------" + " thread:" + Thread.currentThread().getName()); observer.onCompleted(); // 不会往下执行observer的任何方法 System.out.println( "complete after------" + " thread:" + Thread.currentThread().getName()); observer.onCompleted(); // 不会执行到 observer.onNext( "abc" ); // 不会执行到 } } catch (Exception e) { observer.onError(e); } } }); } } |
1
2
3
4
5
6
7
8
9
10
11
12
13
14
|
public static void main(String[] args) { Observable<String> observable = new HelloWorldHystrixObservableCommand( "test" ).observe(); observable.subscribe( new Subscriber<String>() { public void onCompleted() { System.out.println( "completed" ); } public void onError(Throwable throwable) { System.out.println( "error-----------" +throwable); } public void onNext(String v) { System.out.println( "next------------" + v); } }); } |
③HystrixCommand 与 HystrixObservableCommand对比
要想使用hystrix,只需要继承HystrixCommand
或HystrixObservableCommand
,简单用法见上面例子。
两者主要区别是:
(1)前者的命令逻辑写在run()
;后者的命令逻辑写在construct()
(2)前者的run()
是由新创建的线程执行;后者的construct()
是由调用程序线程执行
(3)前者一个实例只能向调用程序发送(emit)单条数据,比如上面例子中run()
只能返回一个String结果;后者一个实例可以顺序发送多条数据,比如demo中顺序调用多个onNext()
,便实现了向调用程序发送多条数据;
④4个命令的执行方法对比
execute()
、queue()
、observe()
、toObservable()
这4个方法用来触发执行run()/construct()
,一个实例只能执行一次这4个方法,特别说明的是HystrixObservableCommand
没有execute()
和queue()
。(1)execute()
:以同步堵塞方式执行run()
。调用execute()
后,hystrix先创建一个新线程运行run()
,接着调用程序要在execute()
调用处一直堵塞着,直到run()
运行完成(2)queue()
:以异步非堵塞方式执行run()
。一调用queue()
就直接返回一个Future对象,同时hystrix创建一个新线程运行run()
,调用程序通过Future.get()
拿到run()
的返回结果,而Future.get()
是堵塞执行的。测试代码如下:
1
2
3
4
5
6
7
8
9
10
11
12
13
|
@Test public void testQueue() throws Exception { // queue()是异步非堵塞性执行:直接返回,同时创建一个线程运行HelloWorldHystrixCommand.run() // 一个对象只能queue()一次 // queue()事实上是toObservable().toBlocking().toFuture() Future<String> future = new HelloWorldHystrixCommand( "Hlx" ).queue(); // 使用future时会堵塞,必须等待HelloWorldHystrixCommand.run()执行完返回 String queueResult = future.get( 10000 , TimeUnit.MILLISECONDS); // String queueResult = future.get(); System.out.println( "queue异步结果:" + queueResult); assertEquals( "hello" , queueResult.substring( 0 , 5 )); } |
(3)observe()
:事件注册前执行run()/construct()
。第一步是事件注册前,先调用observe()
自动触发执行run()/construct()
(如果继承的是HystrixCommand
,hystrix将创建新线程非堵塞执行run()
;如果继承的是HystrixObservableCommand
,将以调用程序线程堵塞执行construct()
),第二步是从observe()
返回后调用程序调用subscribe()
完成事件注册,如果run()/construct()
执行成功则触发onNext()
和onCompleted()
,如果执行异常则触发onError()
测试代码如下:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
|
@Test public void testObservable() throws Exception { // observe()是异步非堵塞性执行,同queue Observable<String> hotObservable = new HelloWorldHystrixCommand( "Hlx" ).observe(); // single()是堵塞的 //System.out.println("hotObservable single结果:" + hotObservable.toBlocking().single()); //System.out.println("------------------single"); // 注册观察者事件 // subscribe()是非堵塞的 hotObservable.subscribe( new Observer<String>() { // 先执行onNext再执行onCompleted // @Override public void onCompleted() { System.out.println( "hotObservable completed" ); } // @Override public void onError(Throwable e) { e.printStackTrace(); } // @Override public void onNext(String v) { System.out.println( "hotObservable onNext: " + v); } }); // 非堵塞 // - also verbose anonymous inner-class // - ignore errors and onCompleted signal hotObservable.subscribe( new Action1<String>() { // 相当于上面的onNext() // @Override public void call(String v) { System.out.println( "hotObservable call: " + v); } }); // 主线程不直接退出,在此一直等待其他线程执行 System.in.read(); } |
(4)toObservable()
:事件注册后执行run()/construct()
。第一步是事件注册前,一调用toObservable()
就直接返回一个Observable<String>
对象,第二步调用subscribe()
完成事件注册后自动触发执行run()/construct()
(如果继承的是HystrixCommand
,hystrix将创建新线程非堵塞执行run()
,调用程序不必等待run()
;如果继承的是HystrixObservableCommand
,将以调用程序线程堵塞执行construct()
,调用程序等待construct()
执行完才能继续往下走),如果run()/construct()
执行成功则触发onNext()
和onCompleted()
,如果执行异常则触发onError()
测试代码如下:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
|
@Test public void testToObservable() throws Exception { // toObservable()是异步非堵塞性执行,同queue Observable<String> coldObservable = new HelloWorldHystrixCommand( "Hlx" ).toObservable(); // single()是堵塞的 //System.out.println("coldObservable single结果:" + coldObservable.toBlocking().single()); // 注册观察者事件 // subscribe()是非堵塞的 // - this is a verbose anonymous inner-class approach and doesn't do assertions coldObservable.subscribe( new Observer<String>() { // 先执行onNext再执行onCompleted // @Override public void onCompleted() { System.out.println( "coldObservable completed" ); } // @Override public void onError(Throwable e) { System.out.println( "coldObservable error" ); e.printStackTrace(); } // @Override public void onNext(String v) { System.out.println( "coldObservable onNext: " + v); } }); // 非堵塞 // - also verbose anonymous inner-class // - ignore errors and onCompleted signal /*coldObservable.subscribe(new Action1<String>() { public void call(String v) { // 相当于上面的onNext() // @Override System.out.println("coldObservable call: " + v); } });*/ // 主线程不直接退出,在此一直等待其他线程执行 System.in.read(); } |
来源: https://www.cnblogs.com/cowboys/p/7655829.html
另外比较 好的spring cloud 教程 https://github.com/forezp/SpringCloudLearning
